钢丝绳电动葫芦
产品说明:
CD1/MD1型电动葫芦具有结构紧凑、自重轻、体积小、操作方便等特点。它既可以单独安装在架空工字梁上，也可以配套安装在电动或手动单梁、双梁、悬臂、龙门等起重机上使用。在精细作业场合，当CD1型电动葫芦的起升速度不能满足要求时，应当选用MD1型双起升速度电动葫芦。
The electric wire rope hoist model CD1 and MD1 have the features of compact,light,small-sized shape and smooth operation.It can be used not only on the overhead rails,but also be used in conjunction with many types of electric or manual cranes such as the single-girder crane,the double-girder crane,the cantilever crane and the gantry crane.The electric hoist model MD1 with double lifting speeds should be used in cases where the hoist model CD1 with single speed cannot meet the requirements for fine adjustments during precision operations.
技术数据：
型号Type |
CD1、MD1 |
起重量Lifting capacity(t) |
0.5 |
1 |
2 |
3 |
5 |
起升高度 Lifting height(m) |
6 |
9 |
12 |
18 |
6 |
9 |
12 |
18 |
24 |
30 |
6 |
9 |
12 |
18 |
24 |
30 |
6 |
9 |
12 |
18 |
24 |
30 |
6 |
9 |
12 |
18 |
24 |
30 |
起升速度Lifting speed(m/min) |
8、0.8/8 |
8、0.8/8 |
8、0.8/8 |
8、0.8/8 |
8、0.8/8 |
运行速度Traversing speed(m/min) |
20 |
20 |
20 |
20 |
20 |
工字梁轨道型号（GB/T706）Rail I-beam |
16~28b |
16~28b |
20a~45c |
20a~45c |
28a~63c |
环行轨道最小半径Min.radius of ring rail(m) |
1.5 |
1.5 |
2 |
3 |
4 |
2 |
2.5 |
3 |
4 |
2 |
2.5 |
3 |
4 |
2.5 |
3 |
4 |
5 |
起升电动机Liftingg motor |
型号Type |
ZD121-4 |
ZD122-4 |
ZD131-4 |
ZD141-4F1 |
ZD141-4 |
ZDS10.2/0.8 |
ZDS10.2/1.5 |
ZDS10.4/3.0 |
ZDS10.5/4.5 F1 |
ZDS10.8/7.5 |
容量Capacity(kw) |
0.8、0.2/0.8 |
1.5、0.2/1.5 |
3.0、0.4/3.0 |
4.5、0.5/4.5 |
7.5、0.8/7.5 |
转速Speed(r/min) |
1380 |
1380 |
1380 |
1380 |
1380 |
相数Phase number |
3 |
3 |
3 |
3 |
3 |
电压Voltage(v) |
380 |
380 |
380 |
380 |
380 |
电流Current(A) |
2.4、0.72/2.4 |
4.3、0.72/4.3 |
7.6、1.25/7.6 |
11、1.4/11 |
18、2.4/18 |
频率Frequency(Hz) |
50 |
50 |
50 |
50 |
50 |
运行电动机Traversing motor |
型号Type |
ZDY111-4 |
ZDY111-4 |
ZDY111-4 |
ZDY111-4 |
ZDM112-4 F1 |
容量Capacity(kw) |
0.2 |
0.2 |
0.2 |
0.2 |
0.5 |
转速Speed(r/min) |
1380 |
1380 |
1380 |
1380 |
1380 |
相数Phase number |
3 |
3 |
3 |
3 |
3 |
电压Voltage(v) |
380 |
380 |
380 |
380 |
380 |
电流Current(A) |
0.72 |
0.72 |
0.72 |
0.72 |
1.4 |
频率Frequency(Hz) |
50 |
50 |
50 |
50 |
50 |
接合次数Number of switching(n/hr) |
120 |
120 |
120 |
120 |
120 |
工作级别Classification grade |
M3 |
M3 |
M3 |
M3 |
M3 |
|
