美国ABLE艾培尔手扳葫芦是美国最大的起重设备制造商,所设计制造的手扳葫芦产品畅销全球, ABLE手扳葫芦具有强度高、使用寿命长、使用简单、所制造的手扳葫芦种类繁多能满足各种起重环境使用需求!美国ABLE艾培尔授权天津宏森特商贸有限公司为中国ABLE艾培尔品牌的手拉葫芦区域分销商。
艾培尔ABLE LB 250型手扳葫芦
Mini LB Specification |
|||
Capacity |
kg | 250 | 500 |
Standard Lift |
m | 1 | 1.5 |
Test Load |
kg | 375 | 750 |
Headroom(hook to hook) Hmin |
mm | 215 | 255 |
Pulling efforts |
kg | 12.5 | 18 |
Chainfall |
1 | 1 | |
Load chain(dia.×pitch) |
mm | Φ4×12 | Φ5×15 |
Dimensions |
A | 92 | 110 |
B | 71 | 84 | |
C | 70 | 125 | |
D | 158 | 278 | |
E | 20 | 23 | |
H | 245 | 310 | |
Φ | 25 | 32 | |
Net weight |
kg | 2 | 3.5 |
艾培尔ABLE-LB-I型手扳葫芦? | ||||||||
Model | LB-I |
75 | 100 | 150 | 200 | 300 | 600 | |
Capacity | {t} |
0.75 | 1 | 1.5 | 2 | 3 | 6 | |
Standard lift | {m} |
1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | |
Running test load | {t} |
1.13 | 1.5 | 2.25 | 3 | 4.5 | 9 | |
Headroom | {mm} |
75 | 100 | 150 | 200 | 300 | 600 | |
Pulling efforts | {kg} |
15 | 20 | 18 | 24 | 38 | 39 | |
Chainfall | 1 | 1 | 1 | 1 | 1 | 2 | ||
Load chain dia | {mm} |
6.3 | 6.3 | 7.1 | 8 | 9 | 9 | |
Net weight | {kg} |
6.9 | 7.1 | 9.4 | 10.1 | 16.3 | 27.2 | |
Dimensions | A |
{mm} |
148 | 152 | 161 | 168 | 191 | 191 |
B |
{mm} |
128 | 128 | 148 | 148 | 180 | 243 | |
C |
{mm} |
295 | 310 | 335 | 350 | 405 | 550 | |
D |
{mm} |
256 | 256 | 368 | 368 | 368 | 368 | |
G |
{mm} |
45 | 48 | 52 | 60 | 66 | 80 |
艾培尔ABLE-LB-II型手扳葫芦 | ||||||||
Model |
LB-II | 75 | 100 | 150 | 200 | 300 | 600 | |
Capacity |
{t} | 0.75 | 1 | 1.5 | 2 | 3 | 6 | |
Standard lifting height |
{m} | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | |
Running test load |
{t} | 1.13 | 1.5 | 2.25 | 3 | 4.5 | 9 | |
Pulling efforts |
{kg} | 14 | 16 | 22 | 26 | 32 | 34 | |
Chainfall |
1 | 1 | 1 | 1 | 1 | 2 | ||
Load chain diameter |
{mm} | 6 | 6 | 8 | 8 | 10 | 10 | |
Net weight | {kg} | 6.2 | 6.5 | 10.8 | 11.2 | 18.5 | 32.5 | |
Dimensions {mm} |
A | 148 | 148 | 172 | 172 | 195 | 195 | |
B | 280 | 280 | 410 | 410 | 410 | 410 | ||
C | 45 | 48 | 52 | 60 | 66 | 80 | ||
D | 96 | 96 | 110 | 110 | 145 | 145 | ||
E | 325 | 325 | 380 | 380 | 480 | 480 |
