美国ABLE艾培尔紧线器

美国ABLE艾培尔紧线器是美国最大的起重设备制造商,所设计制造的手扳葫芦产品畅销全球, ABLE紧线器具有强度高、使用寿命长、使用简单、所制造的紧线器种类繁多能满足各种起重环境使用需求！美国ABLE艾培尔授权天津宏森特商贸有限公司为中国ABLE艾培尔品牌的紧线器区域分销商。

美国ABLE艾培尔HRP紧线器

Ltem no	Tractorcapacity(kg)	Wire pope size	No.of hook	n.w(kg)
HRP010	1000	φ5mmx2300mm	Two	15(4pcs)
HRP015	1500	φ6mmx2300mm	Two	16(4pcs)
HRP020	2000	φ6mmx2300mm	Two	24(4pcs)

?

Ltem no	s.w.l	Conductor dia Recommended	n.w.
A-0500	500kgs	1-10mm	0.25kgs
A-1000	1000kgs	5-20mm	0.85kgs
A-2000	2000kgs	7-20mm	1.20kgs
A-3000	3000kgs	16-32mm	2.50kgs

?

Ltem no	s.w.l	Conductor dia Recommended	n.w.
B-0500	500kgs	1-10	0.32kgs
B-1000	1000 kgs	2.5-16	0.70 kgs
B-2000	2000 kgs	7-20	1.30 kgs
B-3000	3000 kgs	16-32	2.60 kgs

美国ABLE艾培尔HPP紧线器

Model	Gear	Tractor Capacity (kg)	?? Cable	Remar	N.W(kg)
??? P10SF	Single	1000kg	φ5mm×1.8m	Facilitated	11.5(6pcs)
P10DF	Double	1000 kg	φ5mm×1.8m	Facilitated	13(6pcs)
P15SL	Single	1500 kg	φ5mm×2.2m	Light	13(6pcs)
P15DL	Doubie	1500 kg	φ5mm×2.2m	Light	16(6pcs)
P20SH	Single	2000 kg	φ8mm×3m	High quality,Chromeplate	18(6pcs)
P20DC	Doubie	2000 kg	φ8mm×3m	High quality,Chromeplate	19(6pcs)
P20DH	Doubie	2000 kg	φ8mm×3m	High quality	20(6pcs)
P30SF	Single	3000 kg	φ5.6mm×1.8m	Facilitated	25(6pcs)
P30DF	Doubie	3000 kg	φ5.6mm×1.8m	Facilitated	26(6pcs)
P30DS	Doubie	3000 kg	φ5.6mm×1.8m	3Hooks, Facilitated	18.5(4pcs)
P40SH	Single	4000 kg	φ6mm×3m	High quality,Chromeplate	20(4pcs)
P40DH	Doubie	4000 kg	φ6mm×3m	High quality,Chromeplate	21.5(4pcs)
P40SS	Single	4000 kg	φ6mm×3m	3Hooks,Highquality,Chromeplate	21.5(4pcs)
